Name: DEORE XT WH-M8120 27.5"
Brand: Shimano
SKU: EWHM8120LFEBD7X
Availability: OutOfStock

Performance You Can Trust

$0.00

Shipping calculated at checkout.

Wheel

Front

Rear

Pair

Freehub Body

N/A

MICRO SPLINE

Freehub & Cassette Compatibility Chart

Product Locator by Locally

When trail conditions demand reliability, DEORE XT wheels deliver. An offset aluminum tubeless rim and smooth-rolling CENTER LOCK hubs provide stable handling and consistent performance, with MICRO SPLINE compatibility and a 12 mm E-THRU axle.

Durable Alloy Tubeless Rim: Offset aluminum rim promotes balanced spoke tension for stable handling and reliable trail performance

28H Double-Butted Spokes: 2.0–1.8–2.0 mm J-bend spokes deliver strength, durability, and consistent wheel stiffness

Smooth, Reliable Hub Performance: CENTER LOCK hubs with labyrinth seals provide smooth rotation and long-term reliability

MICRO SPLINE Freehub: Smaller spline diameter supports modern wide-range drivetrains, including 10T top gears

Trail-Ready Standards: 27.5” wheels with 148×12 rear E-THRU axle and ZERO dish design support balanced performance across trail wheel sizes.

⚠️ WARNING: Cancer and Reproductive Harm- www.P65Warnings.ca.gov

[{"id":47689309159587,"title":"Front \/ N\/A","option1":"Front","option2":"N\/A","option3":null,"sku":"EWHM8120LFEBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":51303578009763,"product_id":9126825001123,"position":1,"created_at":"2026-07-23T00:34:46-04:00","updated_at":"2026-07-23T00:34:48-04:00","alt":"#wheel_front|#wheel_avant","width":1500,"height":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/tpq2xrabwlwfgha1j2ut.jpg?v=1784781288","variant_ids":[47689309159587]},"available":false,"name":"DEORE XT WH-M8120 27.5\" - Front \/ N\/A","public_title":"Front \/ N\/A","options":["Front","N\/A"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449494","featured_media":{"alt":"#wheel_front|#wheel_avant","id":41006827438243,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/tpq2xrabwlwfgha1j2ut.jpg?v=1784781288"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47830465314979,"title":"Rear \/ MICRO SPLINE","option1":"Rear","option2":"MICRO SPLINE","option3":null,"sku":"EWHM8120LREBD7","requires_shipping":true,"taxable":true,"featured_image":{"id":51303578140835,"product_id":9126825001123,"position":5,"created_at":"2026-07-23T00:34:46-04:00","updated_at":"2026-07-23T00:34:47-04:00","alt":"#wheel_rear|#wheel_arrière","width":1000,"height":1000,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/ptrsaulmiafzpgcfacbh.jpg?v=1784781287","variant_ids":[47830465314979]},"available":false,"name":"DEORE XT WH-M8120 27.5\" - Rear \/ MICRO SPLINE","public_title":"Rear \/ MICRO SPLINE","options":["Rear","MICRO SPLINE"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449579","featured_media":{"alt":"#wheel_rear|#wheel_arrière","id":41006827569315,"position":5,"preview_image":{"aspect_ratio":1.0,"height":1000,"width":1000,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/ptrsaulmiafzpgcfacbh.jpg?v=1784781287"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":47689309192355,"title":"Pair \/ MICRO SPLINE","option1":"Pair","option2":"MICRO SPLINE","option3":null,"sku":"EWHM8120LFEREBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":51303578042531,"product_id":9126825001123,"position":2,"created_at":"2026-07-23T00:34:46-04:00","updated_at":"2026-07-23T00:34:48-04:00","alt":"#wheel_pair|#wheel_paire","width":1500,"height":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/hlmus2pjzh3r0mlp3sl5.jpg?v=1784781288","variant_ids":[47689309192355]},"available":false,"name":"DEORE XT WH-M8120 27.5\" - Pair \/ MICRO SPLINE","public_title":"Pair \/ MICRO SPLINE","options":["Pair","MICRO SPLINE"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449548","featured_media":{"alt":"#wheel_pair|#wheel_paire","id":41006827471011,"position":2,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/hlmus2pjzh3r0mlp3sl5.jpg?v=1784781288"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

{"id":47689309159587,"title":"Front \/ N\/A","option1":"Front","option2":"N\/A","option3":null,"sku":"EWHM8120LFEBD7X","requires_shipping":true,"taxable":true,"featured_image":{"id":51303578009763,"product_id":9126825001123,"position":1,"created_at":"2026-07-23T00:34:46-04:00","updated_at":"2026-07-23T00:34:48-04:00","alt":"#wheel_front|#wheel_avant","width":1500,"height":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/tpq2xrabwlwfgha1j2ut.jpg?v=1784781288","variant_ids":[47689309159587]},"available":false,"name":"DEORE XT WH-M8120 27.5\" - Front \/ N\/A","public_title":"Front \/ N\/A","options":["Front","N\/A"],"price":0,"weight":0,"compare_at_price":null,"inventory_management":"shopify","barcode":"192790449494","featured_media":{"alt":"#wheel_front|#wheel_avant","id":41006827438243,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1500,"width":1500,"src":"\/\/ridecanada.shimano.com\/cdn\/shop\/files\/tpq2xrabwlwfgha1j2ut.jpg?v=1784781288"}},"requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}

Controlled Trail Handling

The offset aluminum tubeless rim and zero-dish construction improve spoke balance, supporting stable tracking and confident cornering at speed. Designed for trail riding, the rim delivers dependable handling through changing terrain and trail conditions.

Smooth Reliable Hub

DEORE XT CENTER LOCK hubs use proven labyrinth seals to maintain smooth rolling while keeping dirt and moisture out. Paired with MICRO SPLINE compatibility and a 12 mm E-THRU axle, they deliver reliable engagement with a simple trail setup.

Specifications

Bearings	Cone
Brakes	CENTER LOCK Disc Brake
Brake Type	CENTER LOCK Disc Brake
External Width	34.7 mm
Freehub	MICRO SPLINE
Front Axle	15 mm E-THRU
Front Weight	875 g
Front Weight 27.5	875 g
Hub Seal	Labyrinth+Contact
Hub Spacing O.L.D. Front	110mm
Hub Spacing O.L.D. Rear	148mm
Internal Width	30 mm
Offset Rim	X
Rear Axle	12 mm E-THRU
Rear Weight	1016 g
Rear Weight 27.5	1016 g
Rim Construction	Hooked
Rim Height	19.8 mm
Rim Material	Aluminum
Spokes	28
Spoke Material	Stainless steel
Spoke Type	J-bend
Tire Type	Tubeless Ready
Tubeless Ready	YES
Wheel Size	27.5"

❮ ❯
